25KM PTP PtMP Wireless Bridge

Model	GZ-WB5acDish-Pro
CPU	QCA9563+QCA9882+QCA8334
Flash	SPI NOR 16MB
DDR2	64MB
5G Band	5.150GHz～5.850GHz
5G WIFI Protocol	802.11 a / n /ac
Maximum rate	900Mbps
Antenna	Integrated 25dBi dual polarization dish antenna
5G Tx power	802.11a	54M	23±2dBm	6M	26±2dBm
	802.11n HT20	MCS7	22±2dBm	MCS0	26±2dBm
	802.11n HT40	MCS7	22±2dBm	MCS0	26±2dBm
	802.11ac VHT20	MCS9	21±2dBm	MCS0	26±2dBm
5G Receiving sensitivity	802.11ac VHT40	MCS9	21±2dBm	MCS0	26±2dBm
	802.11ac VHT80	MCS9	21±2dBm	MCS0	26±2dBm
	802.11a	54M	-75dBm	6M	-92dBm
	802.11n HT20	MCS7	-72dBm	MCS0	-90dBm
5G EVM	802.11a_54M: ≤-25 dB；802.11n_MCS7: ≤-28 dB；802.11AC_MCS9:≤-32dB
frequency deviation（ppm）	±20ppm
Port (WAN)	1*10/100/1000M WAN, support 48V POE
Port（LAN）	1*10/100/1000M LAN
Supply	802.3af，DC 12~24V
Consumption	<10W
Reset Button	Long press for 6-10 seconds to restore factory default configuration
LED	SYS, WAN, LAN, 5G WIFI, signal*4
Size	Φ466mm*260mm
Weight	2.9KG
Environment	Operating temperature: -40°C to 70°C Storage temperature: -40°C to 70°C；humidity：5％～95％（No condensation）
IP grade	IP65
ESD	Air +/-8K，Contact +/-6K
Surge protection	Common-Mode: 4K，Differential-Mode: 2K
