Wireless: |
Standard | 802.11ac/b/g/n, MIMO technology |
Speed | 433Mbps compatible with 5.8GHz 300Mbps b/g/n for 2.4GHz |
Modulation | OFDM = BPSK,QPSK, 16-QAM, 64-QAM DSSS = DBPSK, DQPSK, CCK |
Channel | Ch.1-13 for 2.4GHz Ch.36-165 for 5.8GHz |
Frequency band | 2.412GHz-2.472 for 2.4GHz 5.180GHz-5.825Ghz for 5.8GHz |
Wireless Security | 64/128-bit WEP, WPA / WPA2, WPA-PSK/ WPA2-PSK encryption |
RF Power: |
RF Power | 2.4G: 11n @MCS7:22±2DB, @MCS0:24±2DB. 11g @54M:23±2DB, @6M:25±2DB. 11b @11M:25±2DB, @1M:27±2DB. 5.8G: 11a @54M:22±2DB, @6M:24±2DB. 11n @MCS7:20±2DB, @MCS0:22±2DB. 11ac @MCS9:19±2DB, @MCS0:21±2DB. |
Receive Sensitivity | 2.4G: 11n: -70dbm@MCS7, -88dbm@MCS0. 11g: -72dbm@54Mbps, -88dbm@6Mbps. 11b: -85dbm@11Mbps, -94dbm@1Mbps. 5.8G: 11a: -72dbm@54Mbps, -90dbm@6Mbps. 11n: -70dbm@MCS7, -90dbm@MCS0. 11ac:-60dbm@MCS9, -86dbm@MCS0. |
EVM | 11n: ≤-28 DB 11g: ≤-25 DB 11b: ≤-10 DB 11a: ≤-25 DB |
Hardware: |
Chipset | Qualcomm QCA9531 + QCA9887 |
Memory | 128MB DDR2 RAM |
Flash | 16MB |
Interface | 1 * 10/100Mbps RJ45 WAN Port |
1 * 10/100Mbps RJ45 LAN Port |
1 * Reset button, press 15 seconds to revert to default setting |
Antenna | Build in 5dBi MIMO Antenna |
Power consumption | PoE: A771: IEEE 802.3af, 15W(Full Load) A770: 24V Passive PoE, 12W DC: 12V/1.5A |
Software |
Standard Version | Bandwidth: 20Mhz, 20/40Mhz, 80Mhz |
Operation Mode | Gateway, Wireless AP, Repeater, WISP |
SSID No | 4 SSID for 2.4G, 4SSID for 5.8G |
Factory Default Setting | Yes |
Centralized Management by AC Controller | Yes |
Firewall | DoS, SPI Firewall, IP Address Filter/MAC Address Filter/Domain Filter IP and MAC Address Binding |
Protocols | IPv4 |
Others: |
Package Contents | 750Mbps Dual Band wireless access point Ethernet Cable Quick Installation Guide Setting Accessory |
System Requirements | Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, Windows 8, MAC OS, NetWare, UNIX or Linux |
Environment | Operating Temperature: -20~55 ºC Storage Temperature: -40~70 ºC (-40 ºF~158ºF) Operating Humidity: 10%~90% non-condensing; Storage Humidity: 5%~90% non-condensing |
